CuPy, the NumPy/SciPy-compatible array library for GPU-accelerated computing, is getting better every release. In this post, we'll take a deep dive into the new interpolation and signal processing capabilities that our team has been adding to CuPy.

For those who are not familiar with the project, CuPy has several unique features making it an excellent choice for numerical computation. First, CuPy is a drop-in replacement for NumPy and SciPy and used to perform numerical computation on GPUs, thus allowing developers to create, manipulate, and operate on larger n-dimensional arrays faster than they can on CPUs. As a drop-in replacement, CuPy helps users without knowledge of GPU programming accelerate their existing pipelines, while also accommodating more experienced programmers who want to write low-level GPU routines directly in Python. Second, CuPy conveniently integrates with popular Deep Learning frameworks, such as PyTorch and TensorFlow, and allows developers to efficiently deploy new operators, modules, and functions. And lastly, CuPy is flexible with respect to the hardware used, allowing kernel execution not just on NVIDIA GPUs (via CUDA), but also on AMD GPUs. Support for AMD GPUs is thanks to the HIP integration effort pushed during the past year, thus making CuPy a universal, vendor-free library that can be used regardless of the GPU accelerator available.

Over the past few years, CuPy's compatibility with NumPy has improved to the point that most commonplace and popular APIs are now available, including n-dimensional array creation, operation, and manipulation, linear algebra, fast Fourier transforms (FFTs), and statistics. Given the great progress in replicating the NumPy API on GPU, the next step was to port the extensive SciPy API to support GPUs, as well. This has led to several improvements, such as sparse array support and spatial computation.

Porting SciPy APIs is a significant undertaking. Until recently, there were several modules, such as interpolation and signal processing, that were missing or had a partial API coverage and are critical in scientific applications like image and audio processing, weather, radar and spectral analysis, as well as computational chemistry and sensor design. Given this interest, a joint CZI grant (EOSS Cycle 5) was proposed between Preferred Networks and Quansight Labs in order to reduce the gap between SciPy and CuPy and to specifically port most of the APIs available in the scipy.interpolate and scipy.signal namespaces.

During the first year of the grant work, a team of developers at Quansight Labs have teamed up with CuPy maintainers at Preferred Networks to increase the coverage of interpolation and signal processing subpackages, where, as of CuPy pre-release 13.0.0b1, 18 interpolation and more than 100 signal APIs are now available, including basis splines, regular grid interpolation, and piecewise polynomials for the interpolation module and IIR linear filtering, filter design, linear time invariant systems, and peak finding for the signal processing subpackage.

As expected, all the ported APIs afford a significant performance increase relative to the SciPy CPU reference implementations by exploiting the parallel nature of GPU kernels (whereas CPU implementations are sequential). For example, the new CuPy BSpline implementation has a nearly 10x performance improvement when compared to its corresponding implementation in SciPy, and PPoly has a 32x performance improvement, representing a huge enhancement over CPU implementations.

For those APIs which could not be readily ported from CPU to GPU, new implementations were derived from scientific papers, including the new IIR linear filtering routines, which represent the first time IIR filters can be applied on GPUs from Python. As part of this process, some enhancements and simplifications were also backported to SciPy, such as a major refactor of symmetric IIR filters to leverage IIR linear filtering and second order sections rather than dedicated routines which contained duplicate code.

The following example demonstrates the new capabilities of CuPy in filtering multiple signals in parallel using a GPU. For illustrative purposes, we begin by defining four different signals.

Next, let’s add some noise to the example signals.

Now that we’ve generated our signals, time for the fun part! Let’s do some filtering! In doing so, we’ll extract the noise from each signal using the new signal parallel-processing APIs available in CuPy, namely lfilter and filtfilt. For purposes of comparison, we’ll compare applying lfilter once, applying lfilter twice, and filtering in both forward and reverse directions using filtfilt.

A plot comparing filtering results is displayed below. By visual inspection (and rather cursory analysis!), we can conclude that filtfilt does a better job at recovering the original signals.

As part of this effort, we made several other improvements to other CuPy modules, such as adding special functions for elliptic filters, implementing the matrix exponential in the cupyx.scipy.linalg namespace, and implementing KD-Trees in cupyx.scipy.spatial.

This work would not have been possible without the help of the cuSignal team at the NVIDIA RAPIDS initiative, who agreed to migrate the implementations of over 36 APIs from their project to CuPy, thus unifying the GPU signal processing efforts currently available in the ecosystem. As part of this migration, cuSignal will be deprecated and replaced by the new cupyx.scipy.signal module calls. The calls will be interchangeable by simply replacing the cusignal imports with imports from cupyx.scipy.signal.

As the grant enters its second year, we plan to finish the overall interoperability of the interpolation module, which first requires a significant refactor of several FORTRAN routines for spline smoothing into GPU kernels and, second, implementing computational geometry routines to compute convex hulls and Delaunay triangulations, which are used for interpolating multi-dimensional unstructured data. This work will further enhance overall CuPy-SciPy compatibility.

These new APIs will open a sea of possibilities in terms of acceleration and batch processing of data, and we hope they will be useful to the CuPy community. Right now, these additions are being pre-released as part of the beta releases of the upcoming CuPy v13.0. We invite you to keep an eye on our tracking issues https://github.com/cupy/cupy/issues/7186 and https://github.com/cupy/cupy/issues/7403, where you can find more information on and discussions about implementations, as well as the current progress on the remaining functionality of CuPy’s interpolation and signal modules. Please feel free to chime in and contribute to any discussion or improvement to the project!

We would like to thank the Chan Zuckerberg Initiative (CZI), Preferred Networks, and Quansight Labs for the resources used to plan and execute the current grant. We would also like to thank NVIDIA and the RAPIDS team for their help and willingness to migrate cuSignal into CuPy as part of this work.

In particular, we would like to thank the following individuals on the CuPy team at Preferred Networks: Masayuki Takagi (@takagi), Emilio Castillo (@emcastillo), Akifumi Imanishi (@asi1024) and Kenichi Maehashi (@kmaehashi). Shout out to the Quansight Labs team: Evgeni Burovski (@ev-br), Edgar Margffoy (@andfoy), and Ralf Gommers (@rgommers). And we would like to thank Adam Thompson (@awthomp) and Matthew Nicely (@mnicely) on the cuSignal team for their great effort in making CuPy a complete GPU replacement for NumPy and SciPy.

Finally, we thankfully acknowledge the community contributions to this effort. Specifically, we thank Michael Zhang (@ideasrule) for his porting the RegularGridInterpolator code from SciPy and Leo Fang (@leofang) of NVIDIA for multiple fruitful discussions, as well as other community members for their feedback and suggestions.
